Tractors Worldtrac 90 CV 4WD
Worldtrac 90 CV 4WD
Emei diesel is the farmer's associate supplying the agricultural industry with Solis, Sonalika, Claas and Renault tractors for sale or rent. We also supply other agriculture tools and products
WORLDTRAC - 90 CV 4WD TECHNICAL DETAILS
Tractor Model Worldtrac
Drive 4WD
Engine Details
Model 4100 FLT
Power (HP) 90
Type Turbo Charged Oil Cooler, 4 Stroke Diesel, DL, Pressurized water Cooled Diesel
engine
No. of Cylinders 4
Rated Engine Speed 2200
Torque 339
Air Cleaner Dry Air Cleaner with Clogging Sensor (indicator)
Clutch
Type DC
Plate Size (mm) Ø-310
Transmission
Type Syncromesh, 12F , 12R
Speed Min - 1.62 Km/hr, Max - 33.38 Km/hr
PTO
Type( with Reference Of is : 4931) Double Speed Live PTO / Ground PTO
RPM 540 / 540 E
No. of Splines 6
Brakes
Main Brake Oil Immersed Brake
Parking Brake Independent
Steering
Type Steering Power
Hydraulics
A. Position Control To Hold The Lower Link at any desired height
B. Automatic Draft Control Maintains Uniform Draft
C. Mix. Control For Simultaneous use of Position and draft Control for optimum field output
Lifting Capacity(Kgs) 2500
Linkage 3 Point Linkage CAT 2
Electrical instruments
Battery 12V, 110Ah
Alternator 12V. 36A
Starter Motor Make Mico 12V, 2.5 KW, Make: Lucas 12V, 2.5 KW
Tyres
Front 11.2 x 24
Rear 18.4 x 30
Fuel Tank
Capacity / Type 77.5 Ltrs. / HSD
